ANAND-7018

ANAND-7018 Low Hydrogen SMAW covered electrodes Heavy basic coated low hydrogen electrode with high impact properties at -30 C for producing tougher weld. Weld metal recovery is about 115%, which implies higher productivity. Extremely good slag detachability gives greater weld appeal. Low spatter and finely rippled beads with regular profile reduces post-weld dressing operations. Weld of consistent radiographic quality is achieved.

Classification

AWS A5.1

IS 814

E 7018

EB 54 26 H3 JX

Applications

Suitable for welding Boiler quality

Pressure Vessel Steels welding

Heavy Structure welding

All Weld Chemical Composition

Element	Mn%	C%	Si%	S%	P%
Value	1.20	0.05	0.40	0.02	0.025

All Weld Mechanical Properties

Yield Strength (N/mm²)	Ultimate Tensile Strength(N/mm²)	Elongation (%)	Impact at -30'C (Joules)
470	570	30	100

Operating Data

Position	Polarity	Size (mm)	Current (Amps)	Pieces / Packet	Pieces / Box
	DCEP	2.50 x 350	80-110	135	520
		3.15 x 350	100-130	90	360
		4.00 x 450	140-190	60	240
		5.00 x 450	180-240	40	160
